A.      ENGINE

Make

ASHOK LEYLAND 46 TA C3

133 hp @ 2200 rpm BS4

No. of Cylinder

Six (6)

Cooling System

Water Cooled

B.      CUTTER BAR

Widh (mm)

4400

Heigh Adjustment

Hydraulically

Cutting Height Min.

100 mm

Cutting Heigh Max.

1000 mm

C.      REEL ASSEMBLY

Type

Pick-Up

Speed Adjustment

Mechanically

Height Adjustment

Hydraulically

D.      THRESHING DRUM

Dia of Drum

600 mm

Length of Drum

1260 mm

Speed of Drum

535 to 1210 rpm

Adjustment

Mechanical

No. of Rasp Bars

8 (Eight)

No. of Spikes

152

E.       CONCAVE

Clearance Between

16 to 39 mm

Concave & Thresher

3 to 16 mm

Drum at Intel at Cutlet Adjustment

Mechanically

E.       STRAW WALKERS

No. of Straw Walkers

5 (Five)

Total Area

46565 Sq. Ft.

E.       CLEANING

Area

26962 Sq. cm.

Adjustment

Mechanically

F.       GROUND SPEED

1^st Gear Km/h

1.5 to 3.5

2^nd Gear Km/h

3.5 to 9.0

3^rd Gear Km/h

8.5 to 21.9

Reverse Gear Km/h

3.5 to 9.0

G.     FAN

No. of Blades

5 (Five)

Diamond of Fan

600 mm

Width of Fan

1270 mm

Adjustment

Mechanically

H.      STEERING

Steering System

Hydraulic

I.        TYRE SIZE

Front

18.4 / 15.30

Rear / Trolley

9.00 x 16

J.        DIMENSIONS

Length

8000 mm

Width

4520 mm

Min. Ground Clearance

460 mm

Width

8500 Kgs. (Approx)

K.      WORKING CAPACITY

Wheat

4.5 Acres / hr (Approx.)

Paddy

3.5 Acres / hr (Approx.)s
